CRL 3-Way Blade Switch | Also available with an Oak-Grigsby Switch Here
Optional Treble Bleed | Choose From Two Types
Mallory 150 Polyester Film Capacitor | Choose .01, .022 , .033, or .047 µF
Switchcraft #11 Mono Output Jack
Gavitt Vintage Style Braided Shield Wire
Gavitt Vintage Style Cloth Pushback Wire
Most Common / Recommended Values are Defaulted.
Switching Positions as Follows
Neck & Bridge In Parallel
IMPORTANT- Most "Core" and some "S2" models will not allow the side mount jack to pass through the rear control cavity. If this applies to your guitar, please let me know via the "Special Instructions for Seller" box from the "Cart" page when placing an order. The jack can be left disconnected - or - a separate pre-wired jack can be included at no additional charge.
